RK3588 Series Industry PC
RU-IPC-3588-16-128-N4
The RU-IPC-3588 Series Industrial PC is applicable to edge computing and cloud hosting scenarios. It adopts the high-end RK3588 octa-core processor from Rockchip, with a maximum main frequency of 2.4 GHz.
It features an industrial-grade full-aluminum alloy shell, which provides dustproof, shockproof, and anti-interference performance, as well as excellent heat dissipation. The host can adapt to complex and harsh operating environments, ensuring its stable, reliable, and secure operation.
product details
Core Features
Adopts onboard RK3588 CPU, equipped with multiple network ports, and supports transmission interfaces such as 4G/5G and Wi-Fi, suitable for applications like the Internet of Things (IoT) and industrial control.
Single-layer IO design, conforming to the rugged and thin design requirements for industrial use.
Fanless design with an integrally formed aluminum extruded housing.
1×M.2 NVMe solid-state drive interface.
2×HDMI output interfaces.
1×MINI PCI-E interface supporting 4G, and 1×MINI PCI-E interface supporting Wi-Fi/BT.
Supports watchdog, diskless boot, Wake-on-LAN (WoL), power-on boot, and scheduled boot functions.
Key Features
Mode | RU-IPC-3588-16-128-N4 |
Size | 180*128.5*42mm |
CPU | Rockchip RK3588, an 8-core 64-bit processor with 4xA76 + 4xA55 cores, adopts an advanced 8nm process and has a maximum main frequency of 2.4GHz |
GPU | ARM Mali-G610 MP4 quad-core GPU, supporting OpenGL ES 3.2 / OpenCL 2.2 / Vulkan 1.1, with 450 GFLOPS |
NPU | 6.0 TOPS @ INT8, supporting mixed-precision computing of INT4/INT8/INT16, and enabling network model conversion based on frameworks such as TensorFlow/MXNet/PyTorch/Caffe |
DDR | LPDDR4X 16G |
Onboard eMMC | eMMC5.1 128GB |
SSD | M.2 KEY-M 2280 Slot, supporting PCIe 3.0 NVMe SSD |
Output | 2HDMI OUT, supporting a maximum output of 7680*4320@60Hz |
Input | 1*HDMI INPUT, supporting a maximum input of 3840*2160p@60Hz |
Voice | 1xLine+1xMIC |
Internet | 4x RJ45，(2x 2.5G+2x1000Mbps) |
USB | USB-3.0*2，USB-2.0*2 |
Other interface | 1×RJ45 (Debugging Serial Port), 1×Micro SD Card |
Built-in Interfaces | Built-in 1×M.2 KEY-E 2230 (supports PCIe Wi-Fi module), built-in 1×M.2 KEY-B 3052 (supports USB3.0 4G/5G module) |
Power Adapter | DC-IN 12V（2.5/5.5Power Jack） |
Operating Temperature/Humidity | -20℃ ~ +60℃, Relative Humidity < 95%, No Condensation |
Material/Surface Treatment | High-quality Extruded Aluminum Alloy + SGCC Sheet Metal / Sandblasting & Anodizing + Spraying |
Weight | About 0.4KG |
Operating System | Ubuntu |
